Author Topic: Correct Size Tires for 15x7 Rallye Rims...  (Read 4221 times)

Offline 72ls5fla

  • Jr. Member
  • **
  • Posts: 249
Correct Size Tires for 15x7 Rallye Rims...
« on: December 01, 2010 - 10:34:37 PM »
Hello-
new to the forum and just purchased a real 70 440+6 Cuda.  It currently has Radial TA tires on it and I would like to get the roodyear Polyglass GT tires.

What are the correct size tires for the front and rear.  I do not believe the car has the "hemi" fenders.
Thanks in advance.

Bill
Thanks --

Bill

Cuda-Challenger.com

Correct Size Tires for 15x7 Rallye Rims...
« on: December 01, 2010 - 10:34:37 PM »



Offline Chryco Psycho

  • Global Moderator
  • C-C.com Guru
  • *****
  • Posts: 31760
  • 70 Challenger R/T SE 70 tube Chassis Cuda now sold
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #1 on: December 01, 2010 - 10:39:08 PM »
F60 15 was the original size

Offline 72ls5fla

  • Jr. Member
  • **
  • Posts: 249
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #2 on: December 01, 2010 - 11:18:42 PM »
Thanks for the info....

Bill
Thanks --

Bill

Offline the_engineers

  • Resident
  • *****
  • Posts: 2637
  • Cheap, fast, reliable...pick 2
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #3 on: December 01, 2010 - 11:42:24 PM »
What are "Hemi" fenders? Hear it often, but never thought to ask...
Brooks

1971 'Cuda 360
2004 Infiniti G35 6-spd Coupe
2001 Toyota Solara Convertible
2002 GMC Savana 1500 Explorer Hightop Conversion
1972 Dodge Dart Swinger...keeping the Slant.  Rocking the turbos.

Offline Topcat

  • Permanent Resident
  • *******
  • Posts: 12375
  • Member since 9/16/04
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #4 on: December 02, 2010 - 12:30:55 AM »
« Last Edit: December 02, 2010 - 12:32:34 AM by Topcat »
Mike, Fremont, CA.


Offline Chryco Psycho

  • Global Moderator
  • C-C.com Guru
  • *****
  • Posts: 31760
  • 70 Challenger R/T SE 70 tube Chassis Cuda now sold
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #5 on: December 02, 2010 - 01:59:24 AM »
Welcome Bill BTW
 C.P. / Neil

Offline CarelianCuda

  • Jr. Member
  • **
  • Posts: 109
    • http://bot.fi/3gu
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #6 on: December 02, 2010 - 04:42:37 PM »
1970PlymouthCuda383 FY1xE63xD32xA36xA62xB51xH51xP31xY22.........
2003TruckmastersOkenosDurangoSlt+ PRVx4.7x545RFExNV244x3.55xLSD

Offline 72ls5fla

  • Jr. Member
  • **
  • Posts: 249
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #7 on: December 03, 2010 - 07:47:10 PM »
Thanks everyone for the valuable input..

How much of a real noticable height difference is there between "F" and "E" series?
If there difference is more width than height, I will purchase the "E" series.
I would rather the tire which fills the wheel-well up a better, without being grossly to large.

I will most likely have to get a new speedo gear once I find out just how far off the MPH's are.

In your opinion, who is the best Vendor to purchase restoration/aftermarket parts from?
Im more concerned with fit/finish/correctness than saving a couple bucks here and there.

Bill
Thanks --

Bill

Offline CarelianCuda

  • Jr. Member
  • **
  • Posts: 109
    • http://bot.fi/3gu
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #8 on: December 04, 2010 - 08:08:05 AM »
How much of a real noticable height difference is there between "F" and "E" series?
Tire Size       Design         Section        Overall
Designation   Rim Width     Width          Diameter
E60-15          6.00            8.70            25.50    (340, 383, 440, 440-6 & AAR front)
F60-15          6.50            9.20            25.94    (Hemi)
G60-15          7.00            9.70            26.44    (AAR rear)
1970PlymouthCuda383 FY1xE63xD32xA36xA62xB51xH51xP31xY22.........
2003TruckmastersOkenosDurangoSlt+ PRVx4.7x545RFExNV244x3.55xLSD

Offline challengermaniac

  • Full Member
  • ***
  • Posts: 738
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #9 on: December 04, 2010 - 11:07:38 PM »
Tire Size       Design         Section        Overall
Designation   Rim Width     Width          Diameter
E60-15          6.00            8.70            25.50    (340, 383, 440, 440-6 & AAR front)
F60-15          6.50            9.20            25.94    (Hemi)
G60-15          7.00            9.70            26.44    (AAR rear)

Are the AAR Front & Rear sizes same for the TA?

What would the modern day radial tire size equilvant be to the E60-15 and G60-15 tires?

Charlie
70 Challenger T/A Red
Edmonds, WA

Offline Cooter

  • Sr. Member
  • ****
  • Posts: 1208
  • There goes the lone Challenger............
    • christinecarclub.com
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #10 on: December 04, 2010 - 11:54:32 PM »
Are the AAR Front & Rear sizes same for the TA?

What would the modern day radial tire size equilvant be to the E60-15 and G60-15 tires?


The 235/60/14-15 Is about the same as the 'ol skool "G60"..
The 'ol skool "L60" is around a 275/60/14-15
The 'ol skool "N50" around a 295/50/14-15

However, today it would seem there are ALOT of oddball tire sizes available..I just bought two 245/60/15 which are wider than a 235, but narrower than a 275/60...
Then, there's the 305/50/15, the 325/50/15 and so on...
1958 plymouth Belvedere 2dr hd top "Christine" [OO)====V====(OO]
1969 dodge Charger "General Lee"         [___|______I______|___]
1968 Dodge Dart 2dr sedan 505" Stroker    (O]=0==========0=[O)
1970 Challenger R/T Clone "Kowalski Special"   (OO) [___________] (OO)

Offline the_engineers

  • Resident
  • *****
  • Posts: 2637
  • Cheap, fast, reliable...pick 2
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #11 on: December 05, 2010 - 01:04:29 AM »
Quickie tire sizing info:
On a 235/60R15, 235 is the width in millimeters. 60 is the sidewall ratio...the sidewall height will be 60% of the width. The 15 is the rim diamter in inches. A 255 is roughly 10" wide at the sidewall. A 255/60R15 will be 10" wide with a 6" sidewall and will be roughly 27" tall.

Hope that helps.
Brooks

1971 'Cuda 360
2004 Infiniti G35 6-spd Coupe
2001 Toyota Solara Convertible
2002 GMC Savana 1500 Explorer Hightop Conversion
1972 Dodge Dart Swinger...keeping the Slant.  Rocking the turbos.

Offline CarelianCuda

  • Jr. Member
  • **
  • Posts: 109
    • http://bot.fi/3gu
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #12 on: December 05, 2010 - 08:03:06 AM »
Are the AAR Front & Rear sizes same for the TA?

What would the modern day radial tire size equilvant be to the E60-15 and G60-15 tires?

Yes, both same on AAR & T/A.
225/50R15 & 245/60R15 looks closest to same on radial tires, but i think at tread of old bias ply tires are wider anyway.
Radial tires also rolling a little lower than bias, so maybe the 235 & 255 is better?

With 15" Wheels - 60 series tires
                                  Section        Overall
Metric    Width         Aspect    Height        Diameter
Width    (Inches)       Ratio     (Inches)      (Inches)
195         7.7          60         4.6           24.2
205         8.1          60         4.8           24.7
215         8.5          60         5.1           25.2
225         8.9          60         5.3           25.6
235         9.3          60         5.6           26.1
245         9.6          60         5.8           26.6
255        10.0          60         6.0           27.0
265        10.4          60         6.3           27.5
275        10.8          60         6.5           28.0

Dimensions from: http://www.pontiacserver.com/tires.html
1970PlymouthCuda383 FY1xE63xD32xA36xA62xB51xH51xP31xY22.........
2003TruckmastersOkenosDurangoSlt+ PRVx4.7x545RFExNV244x3.55xLSD

Offline challengermaniac

  • Full Member
  • ***
  • Posts: 738
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #13 on: December 05, 2010 - 11:35:00 PM »
What would the modern day radial tire size equilvant be to the E60-15 and G60-15 tires?


So if I understand correctly, the modern tire equilvent for a TA would be Front 235/60/15  and Rear 255/60/15, correct?

ps: Bill, sorry if I hijacked your thread.
« Last Edit: December 05, 2010 - 11:36:43 PM by challengermaniac »
Charlie
70 Challenger T/A Red
Edmonds, WA

Offline 1970 RT Challenger 1970

  • Full Member
  • ***
  • Posts: 669
Re: Correct Size Tires for 15x7 Rallye Rims...
« Reply #14 on: December 06, 2010 - 12:07:47 AM »
 :popcorn:
